• GPS: L1
• BDS: B1
Antenna AR（dB）≤5@Elev.90°
Out of band suppression point(dBc): 1561-30MHz & 1575+30MHz＞20
1561-50MHz & 1575+50MHz＞40
1561-100MHz & 1575+100MHz＞70
Flatness in band(dB)： ±1
Connector type: N-K
Protection level: IP67
Operating temperature: -40℃-+70℃
Storage temperature: -55℃-+80℃
Feature:
1, Small profile, easy to install
2, High gain, very well to receive signal from lower elevation.
3, LNA adopts pre-filter design to improve anti-interference ability and has industry leading out-of-band signal rejection.
4, Light protection and anti-surge design
